AudioControl Architect Model 1600SE

Kategoria :: Wzmacniacze wielostrefowe
Marka :: AudioControl
Artykuł :: 8610670/0673
Przeznaczenie :: Home office
Kolor :: Black

Opis:

Architect Model 1600SE
16 Channel High-Current Amplifier with EQ

16 channel amplifier. 60 watts per Channel (All Channels Driven). Flexible Dual-Bus Input Selection. Remote/Local Zone Input Trigger. Signal-Sensing Mute Control for Each Channel Pair. Mono-switch for Improved Bridging. Input Bussing and Level Controls. Class H Design for Energy Efficient Cool Operation. Five Band, 16 Channel Custom-Contoured Room Equalizer. LightDrive Anti-Clipping Protection Circuitry. Discrete Channel Protection Against Clipping, Over-Temperature, and DC Offset Prevents All Channels from Being Shut-Down if One Fails. Subsonic Filter – Improves Performance of In-Wall or In-Ceiling Speakers. Remote Power Control. Beefy Rack Mount Brackets Included.
Five Year Warranty

Pobierz pliki:

Architect Model 1680 EQ User Manual [en].pdf

Full Line Catalog [en].pdf

Udostępnij:

Architect Model 1600SE
16 Channel High-Current Amplifier with EQ

It’s really as simple as this! No room, whether commercial or residential, is too large for our Architect series of distributed audio amplifiers. the Architect 1600 SE 16-channel High-Current power amplifier is built for driving more than 2 speakers per zone. Low impedance speaker loads are no problem for this multi-channel amplifier. The proprietary High-Current design enables the Architect 1600 SE to provide over 150 watts per channel into a 4 ohm load and 300 watts per channel when bridged. AudioControl’s Exclusive LightDrive Anti-clipping Circuit allows you to use all of the Model 1600 SE power without the worry of speaker damage.

AudioControl’s revolutionary Class H topology provides the cool-running, energy efficient performance required of a multi-channel amplifier. AudioControl’s legendary speaker equalization creates maximum acoustical performance delivering 5-bands of equalization adjustment optimizing the performance of all speakers connected to it’s 16 channels.

The Architect Model 1600 SE multi-channel amplifier is manufactured in the USA and carries AudioControl’s Bulletproof 5 Year Warranty, but is designed to last a lifetime.

Features

Flexible Dual-Bus Input Selection
Remote/Local Zone Input Trigger
Signal-Sensing Mute Control for Each Channel Pair
Mono-switch for Improved Bridging
Input Bussing and Level Controls
Class H Design for Energy Efficient Cool Operation
Five Band, 16 Channel Custom-Contoured Room Equalizer
LightDrive Anti-Clipping Protection Circuitry
Discrete Channel Protection Against Clipping, Over-Temperature, and DC Offset Prevents All Channels from Being Shut-Down if One Fails
Subsonic Filter – Improves Performance of In-Wall or In-Ceiling Speakers
Remote Power Control
Beefy Rack Mount Brackets Included
Five Year Warranty

Specifications

Inputs

Inputs: 8 Stereo Local Inputs, 2 Stereo Bus Inputs
Input Sensitivity: Variable 0-1 Vrms
Input Impedance: 10kΩ

Outputs

Amplifier Channels: 16
Power Output (8Ω): 60W per channel
Power Output (4Ω): 150W per channel
Power Output (Bridged Mono): 300W
Minimum Speaker Load: 4Ω

Performance

Damping Factor: >200
Total Harmonic Distortion: 0.09% (Full Power, 20Hz-20kHz)
Crosstalk: >80dB @ 1kHz
Equalizer Frequencies: 75Hz, 250Hz, 700Hz, 2.5kHz, 12kHz
PFM Highpass Filter: 40Hz (switchable)

Control

Remote Power Trigger: +12 VDC or Dry Contact Closure

General

Power Consumption (Standby): 40 W
Power Consumption (Idle): 75 W
Power Consumption (loud listetning level): 400 W
Power Consumption (maximum): 2400 W
BTU/Hour Heat Dissipation (Standby): 135
BTU/Hour Heat Dissipation (Idle): 256
BTU/Hour Heat Dissipation (loud listening level): 911
BTU/Hour Heat Dissipation (maximum): 2780
Protection: clipping, short circuit, thermal, ultrasonic, DC offset, stable into reactive or mismatched loads
